Multipurpose
Various types of carrier platforms meet the needs of almost any scenario.
Simple
The installation is tool-free. Just connect the rail ladder sections using eye nuts and bolts and spend 20 minutes to be finished by only two installers (for a 10-meter ladder).
Portable
The small-sized and lightweight design is suitable for regular truck or van transport.
Stable
Smooth start and stop thanks to the frequency conversion control system. (specific models)
Durable
The patented LBS rope groove extends the wire rope service life. The patented VFC system avoids inertia damage without speed changes. The aluminum alloy guide-rail ladder is high-strength and wear resistant.
Reliable
The functions of fall protection, overload detection, power failure protection, and emergency braking prevent damage to the property and personnel.
Rail top section
Features a steel wire rope reversing wheel that secures the wire rope from falling.
Roof support bracket
Provides support to the guide rails on the roof to ensure stability and protect the roof from damage.
Knee section
Allows the rail to fit properly to the roof or other inclined surfaces by adjusting its angles between 20° and 42°.
Carriage
It is welded with carbon steel and offers a safety catch mechanism in case the wire rope breaks.
Multi-purpose lifting platform
It is a convenient and easy-to-use lifting cage for carrying various materials.
Rail section connectors
Connects the guide rail sections by using the designed bolts and eye nuts without tools, while meeting the required torque.
Standard rail sections
It is built of high-strength aluminum alloy and has four standards (2 m / 1 m / 0.75 m / 0.5 m) and customizable lengths per piece.
Guide rail support
Supports the guide rails at various heights thanks to its adjustable length of 5.4 to 7.2 meters.
Lbs grooved drum
Installed in the drive unit, it guarantees the orderly and stress-free winding of multi-layered wire ropes, reducing friction and extrusion deformation and extending service life.
Drive unit
Allows for manual load lowering and easy transportation. The frequency converter control (available only in the mh03l250-expert model) provides a smoother start and stop.
|
Brand |
STONIMAGE |
|
Place of Origin |
HENAN,CHINA |
|
Lifting weight |
150kg-200kg |
|
Pivoting track section adjustment range |
20 degrees to 45 degrees |
|
Customized |
Accept |
|
Lifting height |
4-20m,and the longest does not exceed 25m |
|
Wire rope diam. |
ø6mm |
|
Material |
Channel steel, galvanized square steel, aluminum alloy |
|
Voltage |
110/220,can be customized |
|
Remote control |
Wired or wireless remote control |
|
Model |
Track length |
Max. vertical height (m) |
Max. Load Capacity (kg) |
Motor model/power |
Standard section length (m) |
|
EL400 |
4 |
3~4 |
200 |
PA800, 1300w |
0.5+3.5 |
|
EL500 |
5 |
4~.4.5 |
200 |
PA800, 1300w |
0.5+3.5+1 |
|
EL600 |
6 |
5~5.5 |
200 |
PA800, 1300w |
0.5+3.5+2 |
|
EL700 |
7 |
6~6.5 |
200 |
PA800, 1300w |
0.5+3.5+3 |
|
EL800 |
8 |
7~7.5 |
200 |
PA800, 1300w |
0.5+3+3+1.5 |
|
EL900 |
9 |
8~8.5 |
200 |
PA800, 1300w |
0.5+3+3+2.5 |
|
EL1000 |
10 |
8.5~9.5 |
200 |
PA800, 1300w |
0.5+3+3+2+1.5 |
|
EL1100 |
11 |
9~10.5 |
200 |
PA800, 1300w |
0.5+3+3+3+1.5 |
|
EL1200 |
12 |
10~11.5 |
200 |
PA800, 1300w |
0.5+3*3pc+2.5 |
|
EL1300 |
13 |
11~12.5 |
200 |
PA800, 1300w |
0.5+3*3pc+2+1.5 |
|
EL1400 |
14 |
12~13.5 |
200 |
PA800, 1300w |
0.5+3*4pc+1.5 |
|
EL1500 |
15 |
13~14.5 |
150 |
PA800, 1300w |
0.5+3*4pc+2.5 |
|
EL1600 |
16 |
14~15 |
150 |
PA1000, 1600w |
0.5+3*4pc+2+1.5 |
|
EL1900 |
17 |
15~16 |
150 |
PA1000, 1600w |
0.5+3*5pc+1.5 |
|
EL1800 |
18 |
16~17 |
150 |
PA1000, 1600w |
0.5+3*5+2.5 |
|
EL1900 |
19 |
17~18 |
150 |
PA1000, 1600w |
0.5+3*5+2+1.5 |
|
EL2000 |
20 |
18~19 |
150 |
PA1200, 2000w |
0.5+3*6+1.5 |
|
Selling units |
Single item |
|
Single package size |
210.00cm * 22.00cm * 52.00cm |
|
Single gross weight |
180.000kg |
|
Quantity (sets) |
1 - 1 |
2 - 5 |
6 - 10 |
> 10 |
|
Lead time (days) |
7 |
10 |
15 |
To be negotiated |
